Widely used in all kinds of brick factories, building materials, construction and otherr industries for the shipment of bricks.
- Both sides of the clamping arm are provided with mesh frame guard, which can effectively protect the bricks that have just been made and not yet packaged, ensuring that the bricks will not fall or break during the process of loading.
- With the function of 180° rotation, bricks can be stacked and adjusted in differentt directions according to different working conditions.
- Please obtain the actual load capacity of the forklift / attachment from the forklift manufacturer.
- Requires 2 additional oil circuit for the forklift.
- Other size available on request.
Specification
· Class: Ⅲ
· Opening Rage: 480-1100mm
· Arm Height: 1333mm
· Arm Length: 1473mm
· Frame Width: 1100mm
· Lost Load: 120mm
· VCG: 969mm
· HCG: 832mm
· Rotation Angle: 180°
· Weight: 1087kg
· Suit Forklift: 3-3.5t
