The F-RPC Carriage Mounted Roll Prong is suitable for carpet, vinyl, fabric etc.
- Units are available for Class 2, Class 3 and Class 4 forklift carriages, along with pin mounted.
- Prongs are made from high tensile steel. Enamel paint finish.
- All “QR” model roll prongs are fitted with “Quick Release” mounting locks providing a safe and easy connection to the forklift carriage, saving time and eliminating the need for any tools.
Specifications
• Lost Load for Class 2: 100 mm
• Lost Load for Class 3: 225 mm
• Lost Load for Class 4: 280 mm
|
Type
|
Code
|
φ(mm)
|
PL(mm)
|
SWL(kg)
|
Load Centre(mm)
|
Weight(kg)
|
|
F-RPC-QR2-40-1200
|
03.01.26.0009
|
40
|
1200
|
200
|
600
|
63
|
F-RPC-QR2-50-1800
|
03.01.26.0014
|
50
|
1800
|
250
|
900
|
79
|
F-RPC-QR2-60-2800
|
03.01.26.0002
|
60
|
2800
|
340
|
1400
|
113
|
F-RPC-QR2-70-2800
|
03.01.26.0004
|
70
|
2800
|
510
|
1400
|
135
|
F-RPC-QR2-80-2800
|
03.01.26.0010
|
80
|
2800
|
850
|
1400
|
166
|
F-RPC-QR3-70-2800
|
03.01.26.0011
|
70
|
2800
|
510
|
1400
|
190
|
F-RPC-QR3-80-2800
|
03.01.26.0012
|
80
|
2800
|
850
|
1400
|
220
|
F-RPC-QR3-100-2800
|
03.01.26.0013
|
100
|
2800
|
1700
|
1400
|
282
|
