Suitable for all kinds of paper bags, cotton bags, wool bags, chemical fiber bags and other soft bags material shipment.
- T-type sliding rod material high strength, good wear resistance, long service life. All steel structure, valve and cylinder rod open part of the bafle protection, excellent visual field operation.
- Please obtain the actual load capacity of the forklift / attachment from the forklift manufacturer.
- Requires 2 additional oil circuit for the forklift.
- Other size available on request.
Specification
· Opening Rage: 490-2300mm
· Arm Height: 460mm
· Arm Length: 1200mm
· Frame Width: 1600mm
· Lost Load: 134mm
· VCG: 242mm
· HCG: 318mm
|
Type
|
Class
|
Side Shift
|
Weight
|
Suit Forklift
|
|
F-TRBJ2A20A-1600-2300
|
II
|
No
|
735kg
|
2-2.5t
|
F-TRBJ2A20A-1600-2300
|
II
|
Yes
|
735kg
|
2-2.5t
|
F-TRBJ3A30A-1600-2300
|
III
|
No
|
735kg
|
3-3.5t
|
F-TRBJ3A30B-1600-2300
|
III
|
Yes
|
735kg
|
3-3.5t
|
