Suitable for all kinds of paper bags, cotton bags, wool bags, chemical fiber bags and other soft bags material shipment.
- Structure optimization, good visual field, lighht weight, small lost load, small arm thickness, especially suitable for stowage cargo operation. It has the characterristiccs of high strength and light weight, flexible and convenient operation.
- Please obtain the actual load capacity of the forklift / attachment from the forklift manufacturer.
- Requires 2 additional oil circuit for the forklift.
- Other size available on request.
Specification
· Opening Rage: 580-2300mm
· Arm Height: 500mm
· Arm Length: 1200mm
· Frame Width: 1600mm
· Lost Load: 149mm
· VCG: 289mm
· HCG: 250mm
|
Type
|
Class
|
Side Shift
|
Weight
|
Suit Forklift
|
|
F-YRBJ2A20A-1600-2300
|
II
|
No
|
680kg
|
2-2.5t
|
F-YRBJ2A20A-1600-2300
|
II
|
Yes
|
680kg
|
2-2.5t
|
F-YRBJ3A30A-1600-2300
|
III
|
No
|
680kg
|
3-3.5t
|
F-YRBJ3A30B-1600-2300
|
III
|
Yes
|
680kg
|
3-3.5t
|
