Advanced Technology
Adopt Benz advanced technology, optimize system matching
As for the load demand of heavy duty type of Foton Cummings engine,system is optimized to solve the problem like high gravity center and easy rollover and key spare parts are also optimized.
Adopt Benz development procedure to improve reliability
Adopt Benz technology, advanced development procedure, integrated design together with famous upper body manufacturer to improve the reliability of trucks.
Adopt Benz mature production technology to guarantee products quality
Global high quality purchasing system, digitizing factory and 36 inspection procedures; Adopt Benz mature automatic production technology with more than one hundred years history of pressing, welding, painting and total assembly to guarantee products quality during production.
Powerful
Adopt Wechai and Foton Cummings jet engine with big torque, large cylinder diameter and three air valves technology, with 2000bar super high pressure.
Super Stable
Adopt widened frame to promote the stability and prevent the vehicle to side turn.
Adopt 16T double reducing axle, 220mm widened brake pad, fast heat radiation, improve braking power and make brake safe.
Adopt fast coupling to ensure air circuit air tightness, enough air pressure, short brake response time, brake system safety and reliability are promoted.
Super Safe
Adopt LBSC intellectual recognition and can change gear shift and revolving speed to achieve stable driving.
Real time malfunction remind and remote inspection, Tianyuan intelligent control and behavior analysis.
Adopt iBrake technology, more effective brake can effectively reduce the wear of brake pad and tires and prevent brake is disabled because of over temperature.
Adopt European standard safe cabin, produced by global digitizing heavy duty truck model plants, the entire cabin can move back to 200mm to protect the safety of life and property.
Products Specifications
|
Model NO.
|
Chassis NO.
|
Emission/Fuel
|
Total Weight
|
Kerb Weight
|
Dimension
|
Wheelbase
|
|
WL5251GJBBJ43
|
BJ5253GJB-XL
|
Eu V /diesel
|
25000
|
16600
|
9300,10100,10350×2500×3995
|
4300+1350
|
|
WL5312GJBBJ39
|
BJ5313GJB-XL
|
Eu V /diesel
|
31000
|
18800
|
10900,11450,11700×2500×3990
|
1800+3650+1350,1800+3850+1350
|
|
WL5311GJBBJ31
|
BJ5313GJB-AA
|
Eu V /diesel
|
31000
|
15300
|
9550,10240×2500×3990
|
1800+3050+1350
|
|
WL5310GJBBJ30
|
BJ5312GJB-AA
|
Eu V /diesel
|
31000
|
13500
|
9700,10200×2500×3990
|
1860+3050+1300
|
|
WL5313GJBBJ39
|
BJ5313GJB-XL
|
Eu V /diesel
|
31000
|
15500
|
10900,11450,11900×2550×3990
|
1800+3850+1350,1800+3650+1350
|
