Parameter
A) Model: ZZZ-CK
B) Designed speed: 140m/min
C) Practical speed: 80-120PCS/min
D) Machine size: ( 30× 6× 3)M(L× W× H)
E) Working space: ( 34× 8× 4)M(L× W× H)
F) Machine weight: 28.5T
G) Installed capacity: 150KW (380V 50Hz) Breaker Capacity: 400A
H) Practical capacity: 100KW (380V 50Hz)
I) Air compressor: 1.5 m3/min
J) Electric wire: 3x70 mm2+1x25 mm2+1x16 mm2
K) Product size: S, M, L
L) Container: 2× 40HQ
Configuration
A) Double route forming system with wrapping by tissue, using large and small cotton cores. The products are economic and practical. SAP may be supplied at a fixed amount in designed locations or in a mixing way.
B) Crusher system adopts sawmill or hammer mill with long fiber and better absorbent capacity.
C) Fluff core uses double-moulds forming or aggregate unit.
D) With warning function for SAP in lower place.
E) With standing cuffs, frontal waist tape, sides waist tape, elastic waist tape, elastic rubber for leg mechanism.
F) Main material with constant tension control auto-unwinding, rectifying a deviation guide. (option device)
G) Tri-folded arranging out.
H) With warning and shutting down functions by PLC control, material end detection and rejection system.
I) Driven by frequency. Machine with PLC control and touchable screen.
J) Hot-melt applicator is set in front of the machine. Such bridge style makes it easy to feed the glue and control the temperature. (option device)
