Full color video PH4mm lightweight led billboard waterproof
Pioneering SMD 10000nits for Outdoor LED Screen
Better Performance in Display
High Contrast Ratio
Better Blending Effect in Color
Wider Viewing Angle
Module of hollowed-out design is made for efficient heat dissipation to stand various severe weathers in outdoors. Fully waterproof module can stand the stormy weather in outdoors
Specification:
|
Pixel Configuration
|
SMD1921
|
|
Pixel Pitch（mm）
|
4.0
|
|
Pixel Density（dot/m2）
|
62500
|
|
Module Pixel Matrix （W×H）
|
64×32
|
|
Module Size（mm）
|
256（W）×128（H）
|
|
Module Weight（kg）
|
0.5
|
|
Module Power Consumption Max.（W）
|
25
|
|
Module/Panel（W×H）
|
4×6
|
|
Panel Resolution（W×H）
|
256×192
|
|
Panel Size（mm）
|
1024（W）×768（H）×160（D）
|
|
Panel Weight（kg）
|
28
|
|
Maitainence Mode
|
Rear Maitainence
|
|
Panel type
|
Die casting Aluminum cabinet
|
|
Brightness（nits）
|
≥6500
|
|
Color Temperature（K）
|
3200—9300
|
|
Viewing Angle（Hor/Vert°）
|
140/120
|
|
Power Consumption Max（W/m2）
|
1000
|
|
Power Consumption Avg（W/m2）
|
200-300
|
|
Operating Power Source
|
AC90~264V，frequency 47-63（Hz）
|
|
Frame Frequency（Hz）
|
50&60
|
|
Drice Mode
|
Constant Driving，1/8s
|
|
Gray Scale
|
65536
|
|
Refresh Rate（Hz）
|
≥3840
|
|
Gray Scale per Color Level
|
16bit
|
|
Working Temperature/Humidity（℃/RH）
|
-20 – 60 / 10%-85%RH
|
|
Storage Temperature/Humidity（℃/RH）
|
-20 – 60 / 10%-85%RH
|
