Overview
Brand: Nokia
Product Number: 472678A
Model: FXCB
Discription: NSN Networks Base Station BBU Flexi Multiradio RF Module (GSM 850 90W) FXCB 472678A;
Flexi RF Module Triple (FXxx)
The Flexi Multiradio Radio Frequency Module (FXxx) or RF Module, is a 3-branch multicarrier,multi-standard radio transceiver module. The module consists of three independent branches, capable of transmitting and receiving signals of multiple radio technologies concurrently:
-
Up to 6 GSM carriers with 400 KHz minimum carrier separation
-
Up to 4 WCDMA carriers with 4.6 MHz minimum carrier separation
-
Multi-carrier LTE signal with 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz, 20 MHz, and 35 MHz carrier bandwidth
-
Multi RAT operation with combination of GSM, WCDMA, and LTE
RF Standards
Radio Technology
|
Standard
|
Multi Standard Radio
|
3GPP TS 37.104 and 37.141 release 9 for
FXxA/FHxA/ ESMx and rel 10 for FXDB, FXCB,FXFCFXEB, FHEB and FHDB.
|
GSM/EDGE
|
3GPP TS 45.005 and 51.021 release 8 for
FXxA/FHxB/ESMx and rel 10 for FXDB,FXCB,FXFC and FXEB
|
WCDMA
|
3GPP TS 25.104 and 25.141 release 8 for
FXxA/FXFB/ESMx and rel 10 for FXDB, FXCB,FXFC and FXEB
|
LTE
|
3GPP TS 36.104 and 36.141 release 8 for
FXxA/FXFB/ESMx and rel 10 for FXDB, FXCB,FXFC and FXEB
|
