EPOXY GLASS CLOTH LAMINATED SHEET TYPE G-10
|
|
JY-QC-0920A Date: Jul. 19, 2018
|
|
No.
|
Test Item
|
Test condition
|
Unit
|
Standard Value
|
Testing Result
|
|
1
|
Density
|
‐‐
|
g/cm3
|
≥1.70
|
1.85
|
|
2
|
Moisture Absorption (0.187”)
|
ASTM D-570
|
%
|
0.15 max
|
0.02
|
|
3
|
Breakdown Voltage Condition A
(0.062”) Condition D-48/50
|
ASTM D-149
|
kV
|
45 min
40 min
|
50
47
|
|
4
|
Permittivity (0.187'') Condition A
Condition D-24/30
Condition D-48/50
|
ASTM D-150
|
‐‐
|
5.20
5.40
5.80
|
4.60
4.60
4.70
|
|
5
|
IZOD Impact Strength (0.187”) Length-Wise
Cross-Wise
|
ASTM D-229
|
ft-lb/in
Notched
|
7.0 min
5.5 min
|
15
10
|
|
6
|
Flexural Strength (0.187”) Length-Wise
Cross-Wise
|
ASTM D-790
|
ksi (MPa)
|
55 (380) min
45 (311) min
|
80 (552)
70 (483)
|
|
7
|
Flexural Modulus (0.187”) Length-Wise
Cross-Wise
|
ASTM D-790
|
psi
|
‐‐
|
2,700
2,400
|
|
8
|
Tensile Strength (0.125”) Length-Wise
|
ASTM D-638
|
psi
|
‐‐
|
45,000
38,000
|
|
9
|
Compressive Strength
|
ASTM D-695
|
psi
|
‐‐
|
65,000
|
|
10
|
Hardness Rockwell M
|
ASTM D-785
|
‐‐
|
‐‐
|
M110
|
|
11
|
Bonding Strength (0.500”) Condition A
Condition E-48/50
|
ASTM D-229
|
Lb (kg)
|
2,000 min
1,600 min
|
2,300
2,200
|
|
12
|
Shear Strength (punch type, 0.125”)
|
ASTM D-732
|
ksi (MPa)
|
‐‐
|
25 (172)
|
|
13
|
Temperature Index
|
ASTM D-2304
|
℃
|
‐‐
|
130
|
|
14
|
Coefficient of Linear Thermal Expansion Length-wise
Cross-wise
|
ASTM D-696
|
X 10-5 in./in./°F
|
‐‐
|
0.55
0.66
|
|
15
|
Flammability Rating
|
UL94
|
Class
|
‐‐
|
H-B
|
|
16
|
Dissipation Factor @ 1 MHz Condition A
(0.187”) Condition D-24/30
Condition D-48/50
|
ASTM D-150
|
‐‐
|
0.025
0.035
0.045
|
0.018
0.019
0.020
|
|
17
|
Dielectric Strength (Condition A)
|
ASTM D-149
|
V/mil
|
‐‐
|
800
|
|
18
|
Arc Resistance (0.125”)
|
ASTM D-495
|
Sec
|
‐‐
|
130
|
|
19
|
Comparative Tracking Index (0.125”)
|
ASTM D-3638
|
V
|
‐‐
|
200
|
