The GE IC693MDL741C is a specific output module used in GE’s Series 90-30 PLC (Programmable Logic Controller) system.

**1. **General Description:**
   - **Module Type**: Digital Output Module.
   - **PLC Series**: Part of the GE Series 90-30 PLC system.
   - **Purpose**: Used to control external devices by providing digital output signals from the PLC.

**2. **Specifications:**
   - **Output Channels**: 16 discrete output channels.
   - **Output Type**: Transistor (sourcing) outputs.
   - **Output Voltage Range**: Typically 5V to 30V DC.
   - **Current Rating**: Each output channel can handle up to 0.5A, with the total current rating for the module being 4A.
   - **Isolation**: Provides electrical isolation between the output channels and the internal PLC circuitry.

**3. **Electrical Characteristics:**
   - **Output Voltage**: The module can drive loads requiring a voltage in the specified range, typically 5V to 30V DC.
   - **Output Current**: Each output channel can source up to 0.5A.
   - **Power Supply**: Requires a 24V DC power supply for operation.

**4. **Physical Characteristics:**
   - **Form Factor**: Standard 90-30 form factor, designed to fit in the GE Series 90-30 I/O rack.
   - **Dimensions**: Compact design to fit in a standard I/O slot in the PLC rack.
   - **Mounting**: Plug-in module for easy installation and removal from the PLC rack.

**5. **Features:**
   - **Diagnostic LEDs**: Each output channel has an associated LED indicator to show the status (ON/OFF) of the output.
   - **Configuration**: Typically configured via the PLC programming software to define the operation and behavior of each output channel.
   - **Overload Protection**: Includes built-in protection against short circuits and overcurrent conditions.
