About Product:

SPECIFICATIONS:
Part No: IS200STAOH2A
Manufacturer: General Electric
Function: Terminal Board
Series: Mark VIe
Number of channels: 8
Analog output current: 0-20 mA
Customer load resistance: Up to 900 Ω
Size: 15.9 cm high x 10.2 cm wide
Operating temperature: -30 to 65oC
Technology: Surface mount
Availability: In Stock
Product of Origin: USA

IS200STAOH2A is a Simplex Analog Output Terminal Board manufactured and designed by General Electric as part of the Mark VIe Series used in Distributed Control Systems. Compact analog output terminal boards are available, such as the Simplex Analog Output (STAO) terminal board, which is made for flat or DIN-rail mounting. Eight 0-20 mA analog outputs on STAO are powered by the PAOC I/O pack. Similar to the TBAO terminal board, the onboard circuitry and noise reduction are present. The board is equipped with high-density Euro-block style terminal blocks for connecting to the customers' devices. The board is identified to the I/O processor by an onboard ID chip for system diagnostics. The D-type connector is used to connect the I/O pack, which uses Ethernet to talk to the controller.

INSTALLATION:
The STAO and a plastic insulator are mounted in a panel or on a DIN-rail-mounted sheet metal carrier. The STAO plus insulator mount can also be attached to a sheet metal assembly that is bolted directly to a cabinet. Driven equipment can be placed up to 300 meters (984 feet) away from the turbine control cabinet and shouldn't have a resistance greater than 900. There are two varieties of Euro-block terminal blocks:
--An unpluggable mount terminal block with 36 terminals is present on STAOH1.
--A permanently installed terminal block with 36 terminals is present on STAOH2.
