Products Detail:
|
Brand
|
General electric
|
|
Part Number
|
IS215ACLAH1A
|
|
Product Type
|
Control Layer Module
|
|
Payment
|
T/T,100% advance payment
|
|
Shipping Port
|
Xiamen,China
|
|
Lead Time
|
In stock
|
SPECIFICATIONS：
Part Number: IS215ACLAH1A
Manufacturer: General Electric
Series: EX2100
Product Type: Application Control Layer Module
Technology: Surface Mount
Operating System: QNX Neutrino
Programming: 16-bit signed integer
Power Requirements: +5 V dc
Memory: 256 MB
Common Mode Voltage Range: ±5 V
Dimensions: 11.00 x 9.00 x 3.00
Operating temperature: 0 to 60 °C
Primary Ethernet Interface: 10BaseT/100BaseTX
No.of Analog Voltage Inputs: 6
Repair: 3-7 Day
Availability: In Stock
Country of Origin: United States
Manual: GEI-100434A
About IS215ACLAH1A:
IS215ACLAH1A is an Application Control Layer Module manufactured and designed by General Electric as part of the EX2100 Series used in GE Excitation Control Systems. The IS215ACL_ Application Control Layer Module (ACL) is a microprocessor-based master controller that performs multiple duties over communication networks such as EthernetTM and ISBus. The ACL mounts in a standard Innovation Seriesô drive or EX2100 exciter board rack and occupies two half-slots. The ACL and board rack are located in the control cabinet. In drive applications, the ACLís P1 connector (4-row 128-pin) plugs into the Control Assembly Backplane Board (CABP). In the EX2100 exciter, the ACL mounts in the Exciter Backplane (EBKP). The ACL can be ordered in two different I/O configurations as follows:
---IS215ACLAH1A Module with one 10BaseT Ethernet port and two serial communication ports (COM1 and COM2), as used in the EX2100.
---IS215ACLIH1A Module with one 10BaseT Ethernet port, two serial communication ports (COM1 and COM2), and two ISBus ports.
