GE Fanuc IC695PSD140 Module

Serial Ports

The two serial ports are software-configurable for SNP slave or RTU master or slave operation. 4-wire and 2-wire RTU are supported. If a port is being used for RTU, it automatically switches to SNP slave mode if necessary. Port 1 can also be configured for Local Station Manager operation to provide access to diagnostic information about the Ethernet interface. Both ports default to SNP slave and both automatically revert to SNP slave when the CPU is in Stop mode if configured for Serial I/O. Either port can be software-configured to set up communications between the CPU and various serial devices. An external device can obtain power from Port 2 if it requires 100mA or less at 5VDC.

Features

• 128kB of configurable memory

• Programming in Ladder Diagram, Sequential Function Chart, and Instruction List

• Non-volatile flash memory for program storage • Battery backup for program, data, and time of day clock

• Run/Stop switch

• Floating point (real) data functions

• Embedded RS-232 and RS-485 communications

• Embedded Ethernet interface

• 70mm height when mounted on DIN rail with power supply
