GE FAUNC IC698CRE030 CPU

The IC698CRE030 is a GE CPU Module.

  • Shipping PortXiamen
Facebook Twitter Pinterest LinkedIn 分享

 » Description
 Manufacture  GE
 Model  IC698CRE030
 Product ID  IC698CRE030
 Catalog  GE FANUC
 Description  IC698CRE030 CPU
 Origin  United States (US)
 Dimension  34 mm x 145 mm x 140 mm
 Weight  1kg



IC698CRE030



IC698CRE030



The IC698CRE030 is a PACSystems RX7i Central Processing Unit. The RX7i CPU is programmed and configured by programming software to perform control of machines, processes, and systems in real time. It is able to communicate with I/O and smart option modules over a rack-mounted backplane using the VME64 Standard format. An embedded Ethernet port or serial port enables the CPU to communicate with the programmer and HMI devices. This particular model utilizes a 600MHz Pentium-M microprocessor (64 MB both user memory and flash).
Highlights of this unit include HSB or hot standby redundancy, battery-backed user memory and non-volatile flash memory allowing for program, configuration, register data, and symbolic variable storage. It features programming in Ladder Diagram, C, Structured Text, and Function Block Diagram. Auto-located Symbolic Variables conveniently use unlimited memory. A number of modules are supported, including 90-70 Series discrete and analog I/O as well as VME modules.
The IC698CRE030 CPU allows both data monitoring across the web and a maximum of 16 web server/FTP connections. Block size may not exceed 128KB, but 512 program blocks are supported. Power requirements for the IC698CRE030 are as follows: +5 VDC: 3.2 Amps nominal, +12 VDC: 0.003 Amps nominal, and -12 VDC: 0.003 Amps nominal.



  •  » Datasheet Link

GE FANUC IC698CRE030 CPU Datasheet
