Manufactured by GE Automation, the IC698CPE020 is a CPU from the PACSystems RX7i series. It is capable of real-time machine control and communicates with other rack modules via a standard VME backplane. Operation and control of the IC698CPE020 is accomplished by a connected computer or by an on-board three-position switch, which can be disabled if desired
RAM and NVRAM can be used for user data, programming configuration, storing symbolic variables, and any information associated with the register. The operating system firmware is also stored in NVRAM. To update firmware, simply connect the IC698CPE020 to a computer using the proper serial port and run the update software.
Follow the procedures outlined in the manual while installing. Record the device’s MAC address. Power off the rack. In rack slot one, insert the IC698CPE020. Connect the device to the Ethernet LAN. Restore rack power. Connect the CMOS battery.
