Product Description：
The QuickPanel, jr. is a practical and cost-effective replacement for a variety of discrete devices, from
push buttons and pilot lights to message centers. Despite its small size, the QuickPanel, jr.’s 5" or 6"
diagonal screen with 320 W x 240 H pixel format provides a sharp display in color or monochrome.
Each unit communicates with all major PLCs and PLC networks including A-B Remote I/O, Data
Highway Plus, Modicon Modbus Plus and GE Fanuc Genius® (some require an optional, field-installed
module). The industrially designed QuickPanel, jr. is rated NEMA 4X/12. Best of all, its simple yet
versatile design will increase your productivity at a lower installed cost.
Like their smaller counterparts, these larger members of the QuickPanel family are practical and
cost-effective replacements for a variety of discrete devices, from push buttons and pilot lights to
message centers. The 12.1" diagonal display has 800 W x 600 H pixels, the 10.5" diagonal display has
640 W x 480 H pixels and the EL has a 9" diagonal screen with a 640 W x 480 H pixel format. Each provides a bold, clear display. Dynamic graphics can be added to present information-rich pictures to the
operator in a single glance. Each unit communicates with all major PLCs and PLC networks including
A-B Remote I/O, Data Highway Plus, Modbus Plus and GE Fanuc Genius (some require an optional,
field-installed module). All this comes in a slim-line, compact package.
