Products Detail:
|
Brand
|
General electric
|
|
Part Number
|
IS200UCVEH2A
|
|
Product Type
|
UCVE Controller Module
|
|
Payment
|
T/T,100% advance payment
|
|
Shipping Port
|
Xiamen,China
|
|
Lead Time
|
In stock
|
SPECIFICATIONS:
Part Number: IS200UCVEH2A
Manufacturer: General Electric
Series: Mark VIe
Board Type: UCVE Controller Module
Input Voltage Range: 3.3V to 5V DC
Signal Voltage Levels: TTL/CMOS compatible
Maximum Delay Compensation: Up to 100 ns
Clock Frequency: Up to 200 MHz
Operating Temperature Range: -30°C to +85°C
Dimensions: 25 mm x 25 mm x 5 mm
Mounting Type: Surface-mount technology
IS200UCVEH2A is a UCVE Controller Module manufactured and designed by General Electric as part of the Mark VIeS Series used in GE Distributed Turbine Control Systems. It features a 300 MHz Intel Celeron processor, providing adequate processing power for control and monitoring tasks. The board is equipped with either 16 or 128 MB of flash memory, offering storage for system firmware and software applications. The UCVEH2 is the standard Mark VI controller in the following figure. It is a single-slot board using a 300 MHz Intel Celeron processor with 16 Mb of flash memory and 32 Mb of DRAM. A single 10BaseT/100BaseTX (RJ-45) Ethernet port provides connectivity to the UDH. The UCVEM_ _ modules have all the features of the UCVEH2 with the addition of supporting additional Ethernet ports and Profibus. Some UCVEM_ _ modules support secondary 10BaseT/100BaseTX Ethernet ports for use on a separate IP logical subnet. Configuration of the secondary Ethernet port is performed through the toolbox. The controller validates its toolbox configuration against the existing hardware each time the rack is powered up. A separate subnet address allows the controller to uniquely identify an Ethernet port.
