The GE DS200TBQCG1ABB is an analog input board used in General Electric's Mark V Series of gas and steam turbine control systems. Here's a brief overview of its features and functionality:
Key Features:
Analog Inputs: The board is designed to handle analog signals from various sensors and transducers. These inputs are used to monitor and control various parameters such as temperature, pressure, and flow rates.
Signal Conditioning: It provides signal conditioning to ensure accurate data acquisition and reliable operation. This includes filtering, scaling, and converting the analog signals to a form suitable for processing by the control system.
Interface: The DS200TBQCG1ABB interfaces with the Mark V control system's processor and communication modules, enabling it to relay analog information to the central control system.
Diagnostics and Troubleshooting: The board includes diagnostic features to monitor its own health and performance. It can help identify issues related to signal input or internal malfunctions.
Installation: Typically, it is mounted in a standard rack or panel within the turbine control system. Proper installation and configuration are crucial for optimal performance.
|
