General Electric DS200UPSAG1AFD POWER SUPPLY BOARD

General Electric DS200UPSAG1AFD POWER SUPPLY  BOARD

Dimensions:

28x21.2x3.5cm

Weight:

0.46kg

Master Gateway：

-20 to 25°C

Voltage：

132VDC

Bussman type MDA-4, 4A, 250 V; SSC rating 200 A or equivalent
Bussman type AGC-3, rated 3A, 250 V; SSC rating 100 A or equivalent; FU2, FU4 FU3 - ABC-12
Bussman type, rated 12A, 250 V; SSC rating 750 A or equivalent

DS200UPSAG1AFD

GE DS200UPSAG1AFD Power Supply Board is used in the GE Speedtronic Mark V gas turbine control system.

Here are some key details about the GE DS200UPSAG1AFD:

Function: It provides power to the various components of the Mark V control system.

Features:

One reset button

Three fuses

Three 9-pin connectors for ribbon cables

Several capacitors

Test points for diagnosing faults

An LED (light-emitting diode) that does not necessarily indicate the board's functionality

Important note: When replacing this board, it's crucial to ensure the 9-pin cables are reattached to their original connectors to maintain functionality. It's recommended to label or tag the connectors beforehand for accurate reattachment.
