Technical Specifications for IC200ALG620
|
Manufacturer
|
General Electric
|
|
Condition
|
100% New Original
|
|
Brand
|
General Electric
|
Filter Response
|
28 Hz ±20%
|
|
Part Number
|
IC200ALG620
|
Input Range
|
125 mA
|
|
Product Name
|
Analog Input Module
|
Voltage Range
|
5 V
|
|
Manufacture Year
|
2022
|
Power
|
5 Watts
|
|
Product Package
|
Original Package
|
Shipping term
|
TNT DHL FEDEX EMS UPS
|
About IC200ALG620
|
The IC200ALG620 is unique in that it requires no external power supply as the excitation current for the RTD is provided by the module when configured to the RTD type. The RTD Analog Input Module allows inputs from four independent three or four wire RTDs. These can be platinum, nickel/iron, nickel, or even copper depending on user preference and availability.
The IC200ALG620 offers two data acquisition rates based on the 50 or 60 Hz line frequencies. The RTD input module provides for four words on input data and is compatible with a number of PLC CPU and NIU versions of 1.10 or higher in most cases.Each channel in the IC200ALG620 module can be configured as either inactive or active based on user needs.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
