The IC697PWR711 power module from GE Fanuc has been designed and manufactured as part of the GE Series 90-70 line of industrial power modules. power module can provide other modules and systems with either AC or DC power, and its nominal voltage ratings are 120/240 Volts AC and 125 Volts DC. It can also deliver 100 Watts of maximum output power.
|
|
|
IC697PWR711 Data sheet
|
can be used in a single rack application or may to provide power to a second rack if the total load is within the supply rating. A prewired cable allows interconnection to the second rack.
|
|
The power supply output will ride through at least one input line cycle with a total loss of input power at full load. Protection is delivered for overcurrent and overvoltage fault conditions.
|
|
+5 VDC output up to 20 amps; +12 VDC output up to 2 amps; -12 VDC output up to 1 amp. Other highlights include slide-in rack mount construction, electronic short circuit overcurrent protection
|
|
