Product parameters
|
Brand/ Manufacturer:
|
General Electric
|
|
Dimensions:
|
21.6 cm x 23 cm x 25 cm
|
|
Weight:
|
7.62kg
|
|
Country Of Origin: :
|
USA
|
|
ADDITIONAL INFORMATION:
|
Transformer Protection System
|
|
WARRANTY
|
1 YEAR
|
|
MANUFACTURER PART NUMBER
|
SR745-CASE 745-W2-P5-G5-HI-T
|
|
SHIPPING:
|
DHL /Fedex /TNT / UPS/EMS
|
Add information
The Multilin 745-W2-P5-G5-Hi-T Transformer Protection System has options as designated by the R and the T. The R indicates a restricted ground fault option. The restricted ground fault option for the 745-W2-P5-G5-Hi-R-T has two elements. It has a dropout level of 97 to 98 percent of pickup. The slope range in steps of 1 ranges from 0 to 100 percent. The pickup delay is listed in the manual at 0.00 to 600.00 s in steps of .01.
The T option is the highest option that may be selected for display and ethernet. The three options are either basic (B), enhanced display and a larger LCD (E), and finally an enhanced display, larger LCD, with an Ethernet (T). The 745-W2-P5-G5-Hi-R-T transformer protection system has the final option or the T option, which does include the larger LCD, and an ethernet. The display is enhanced when compared to the basic option.
