Features:
1. Construction pre-engineered and fewer components, internationally accepted and meets the building code specifications
2. Higher energy savings due to low thermal conductivity
3. Flexibility in design and choosing various options on fascia of panels and colours
4. All weather proof construction and Maintenance free
5. These insulated panels gives long lasting value with controlled quality, accuracy & speed of construction and caters for better functionality and application.
Specification
|
Length
|
20'GP: no more than 5.85 meter/pcs (19.2ft)
|
|
40'GP/40'HQ: no more than 11.85 meters/pcs (38.9ft)
|
|
Materials
|
Polystyrene foam board(EPS)
|
|
Color steel sheet
|
|
Thickness
|
Color steel sheet: 0.3-0.6 mm
|
|
Polystyrene foam board: 50 mm; 75 mm; 100 mm; 150 mm; 200 mm (1 inch=25.4 mm)
|
|
Insulation Core type
|
EPS foam board(Density 8kg/m3-25 kg/m3)
|
|
Color
|
According to the RAL
|
|
Package
|
PVC foil
|
|
Usage
|
Various roofs and walls referring to the large size industry factory,storages, gymnasiums, etc.
|
