Frequency:1575.42 MHz& GLONASS:1610MHz
Bandwidth:±5 MHz
VSWR:≤1.5.0
Gain:2dBi
polarization:RHCP
dimension:20x20x7.6mm
Input Impedance:50Ω
Connector Type:SMA straight MALE
LNB GAIN:28±2 dB
cable:RG174
Noise Figure:1.5 dB
Filter Out Band Attenuation:30dB Min f0+40MHz
30dB Min f0-40MHz
40dB Min f0+100MHz 35dB Min f0-100MHz
DC Voltage:3~5 V
DC Current:5~10 mA
