Guangzhou AC Ventilating Gearbox HVLS Ceiling Fans

The hvls fan is typically of 5(in odd number) pcs of large diameter blades up to 7.2m each with the effective coverage of 1500SQM. It consumes only 1.5KW electricity per hour, which can replace hundreds 30 sets wall-mounted fans.


  • Air coverage1450SQM
  • Max rotate speed55RPM
  • Max air speed4.5m/s
  • Power supply voltage AC
  • Rated voltage220/380V
  • Power1.1/1.5kw
  • Frequency50/60HZ
  • Noise50db

Guangzhou AC Ventilating Gearbox HVLS Ceiling Fans

1.Taking advantage of American advanced technology, we manufacture the large gearbox HVLS ceiling fans with propeller blades, which guarantees continuous air flow in the room even if the fan rotates very slowly.

2.The air speed of this ceiling fan is 2-3m/s, which can make people free very comfortable.

3.Moves an enormous amount of air (High Volume) with only 50Rpm (Low Speed).

4.Fans can cover an area of at least 1500 square meters.

5.Outstanding energy-saving effect, low energy consumption.



Guangzhou AC Ventilating Gearbox HVLS Ceiling Fans

Market Price

$2700

Factory Price

$2000-$2500

Price Range

1 - 30 sets/$2500-$2700

Price Range

30 - 100 sets/$2000

Product Origin

China

Shipping Port

Guangzhou, Shenzhen

Lead Time

5-15 Days

Payment & Shipping

T/T, L/C, D/A, D/P, Western Union, Money Gram



Model

HV-7200

HV-6200

HV-5200

HV-4200

Fan Diameter(mm)

7200

6200

5200

4200

Blade Numbers

5

Motor Power(kw)

1.5Kw/1.1Kw

Rated Voltage(V)

AC 380V

Rated Frequency(Hz)

50Hz/60Hz

The Maximum Air Speed(m/s)

4.5

4

3.5

3

The Maximun Totate Speed(RPM)

55

58

62

65

Total Weight(Kg)

115

110

105

100

Area Coverd(sq.m)

1450

1300

1100

900

Material Of Chassis And Fan Blade

Aluminum Magnesium Alloy


(1)Motor

Introducing Imported Germany Bauer motor integrated with decelerator, with fluorine rubber oil seal to ensure the reliability of the rotary drive member.

Voltage: 220/380v,50Hz/60Hz, three phase.


(2)Control Box

Reduce gently and intelligently, to protect motor reducer and transmission system.

Frequency converter with over current and over voltage/under voltage/open phase/over load/overheat protection, make it automatic power-off when have an accident.


(3)Fan blades

1.7075 aviation aluminum magnesium alloy with T6 anodizing heat treatment.High resistance to deformation and anti fracture.Tensile strength is 572mpa, the thickness is 2.00mm.
2.5 strength ribs in the inner fan, and one is 3mm thickness for more strong structure and not easy to deform and bench.

3.Connection: 3 bolts which made of 30CrMnSi with thread fastening agent to prevent loosening.


(4)Chassis

Made of aluminum alloy.

Using integrated aluminum magnesium alloy and made by precise cutting technology to ensure the consistency of the chassis as well as security stability.


(5)External load-bearing

Oriented  distance extended Qixiang industrial fan is different from other manufacturers for that double external load bearing designed by Qixiang alone, and extend oriented distance of fan, avoid reducer from axial force, prevent oil spiling,to extend the service life.


 hvls big ceiling fan prices


(6)High Strength Bolts

High Strength Bolts in level 12.9, made of 30CrMnSi with thread fastening agent to prevent loosening.



(1)Three ways to install

A: Installation on H Beam or I Beam structure steel: using pressing plate of 8mm thickness to fix.
B: Fixing on steel concrete beam: using 8 mm thickness 90 degree, using the wearing screw or expansion screw, fixing both right or left.
C: The fixing of grid structure:using v structure or semi-circle to hoop bolts tension.


(2)Pay attention to :

1. Suitable for any building with a ceiling height of 4 meters or more. The spacing of the structural loading columns should be greater than 20% of the fan diameter to be installed.

2. The load bearing capacity of the roof structure should be more than 150kg, the total weight of the fan equipment is about 125kg(including installation accessories and dynamic load), torque 300N/m, noise level<39db.

3. The distance recommended from airfoil to the floor is 6-8m, Mininum should not be less than 4 meters.

4. Make sure that the fan is installed without chandeliers or other obstructions.

5. It’s not recommend for installation at the site with heat sources or soot.



220v cooling fan



1. Qixiang is founded in 2006, is a professional manufacturer engaged in the research, development, production, sale and service of HVLS industrial ceiling fan, gearless direct drive PMSSM HVLS ceiling fan, industrial doors and dock leveler.


2. We have more than 100 well known testimonial customers, such as SAIC GM Wuling, FAW Volkswagen, GAC Hino, Pepsi China, Foxconn Group, Panasonic, Midea Group and the South Logistics Group so on.


3. We have passed I S O 9 0 0 1: 2 0 0 8 certification  CE, RoHS certification. With years of experience in exporting,our products are popular in Southeast Asia, South Asia, Central America, South Africa as well as European countries.


4. Industrial ceiling fans can improve airflow, create 1-3 level soft natural wind quiet more healthy.


5. It is higher technical threshold inner-rotor design, nature cooling, zero maintenance, compact size, IP64 class and super quiet.
