H901GPHF Huawei MA5800 Series 16-port C+ GPON Board

As a telecom equiment supplier for more than 9 years, Skyward Telecom can provide Huawei H901GPHF 16 Ports GPON Board at good quality and low wholesale price.



Overview

Brand Name:  Huawei

Model Number:  H901GPHF

Discription:  Huawei MA5800 series 16-port GPON OLT Interface Board with C+ module

  • Apply to Huawei MA5800 X2, X7, X15, X17 NG OLT system
  • Support split ration 1:128
  • Transmit Speed: 2.49Gbit/s, Receive Speed: 1.24Gbit/s
  • Interface Type: SC/PC
  • Max Transmit Distance: 20KM
  • Transmit Wavelength: 1490nm, Receive Wavelength: 1310nm
  • Standards Compliance: ITU-T G.984.1, ITU-T G.984.2, ITU-T G.984.3, ITU-T G.984.4
  • C+ SFP Module Optical Power: 3 dBm~7 dBm, Receiver Sensitivity: -32 dBm

Specification of H901GPHF


Service ports

GPON Port

16-GPON Port

GPON SFP Module Specification

Type

C+ Module : One-fiber bi-directional optical module, class C+

Operating Wavelength

Tx: 1490 nm, Rx: 1310 nm

Encapsulation Type

SFP

Port Rate

Tx: 2.49 Gbit/s, Rx: 1.24 Gbit/s

Minimun Output Optical Power

C+ Module : 3.00 dBm

Maximum Output Optical Power

C+ Module : 7.00 dBm

Maximum Receiver Sensitivity

C+ Module : -32.00 dBm

Optical Connector Type

SC/PC

Optical Fiber Type

Single-mode

Reach

20.00 km

Overload Optical Power

C+ Module : -12.0 dBm

Extinction Ratio

8.2 dB

Device Specifications

Dimensions (W x D x H)

23.30 mm * 257.90 mm * 399.20 mm

Power Consumption and Maximum Frame Size

Power Consumption

Static: 25W; Maximum:50W

Maximum Frame Size

2004 bytes
9216 bytes (jumbo frame enabled)

Operating temperature

-40°C to +65°C
