No.of Cells:
|
144pcs 166*83mm Mono Cell
|
Model:
|
LC450-144M
|
|
Power:
|
450W+ 0~5W
|
Product Warranty On Materials And Workmanship:
|
10YEARS
|
|
Linear Power Output Warranty:
|
25YEARS
|
ISO14001:
|
2015
|
|
ISO9001:
|
2015
|
Material:
|
Cells
|
|
High Light:
|
350W Mono Solar Panel
300W Solar Power Panel
PERC Half Cell Solar Panel
|
Solar Power Panel 300W 330W 350W 380W 400W 500W 1000W Solar Panel for Electricity
Parameter:
|
Model Number
|
LC(430-455)-144M
|
|
Cell Type
|
Mono, Half Cell
|
|
Place of Origin
|
Hefei city, Anhui Province, China
|
|
Brand Name
|
Sunerise
|
|
Type
|
PERC, Half Cell, Bifacial, Double-glass, All Black, MWT
|
|
Dimension
|
2115*1052*35mm
|
|
Panel Efficiency
|
20%
|
|
Certificate
|
TUV,CQC,CE,IAF,CNAS,ISO etc
|
|
Warranty
|
25 years
|
|
Weight
|
21KG
|
|
No. Of Cells
|
144Pieces
|
|
Max Power at STC
|
430-455W
|
|
Open Circuit Voltage
|
50V
|
|
Short Circuit Current
|
11.4A
|
|
Voltage at Maximum Power Point
|
41V
|
|
Current at Maximum Power Point
|
10.8A
|
|
Power Tolerance
|
0~+5W
|
Product Details
*Anti-reflective glass
*High-transmittance and low reflection Increase model efficiency
*High mechanical strength
Solar Cell
*High model efficiency up to 20%
*High shunt-resistance: adapt the several environmental conditions
*High PID resistant
* Low breakage rate
*Uniform color
Frame
*Optional silvery or black frame
*Tensile Strength Frame
*Boost bearing capability and prolong service life
Junction Box
*Waterproof Junction Box
*Innovative Full-Glue-Filled Combination of series circuit and parallel circuit,
reduced internal power loss Quality diode ensures module running safety
*Heat dissipation
*Long service life
Production & QC
Automatic typesetting machine
After setting up the program according to the requirements of the process drawings, the typesetting machine will automatically
typeset the battery string. High precision, high efficiency, low defect rate
Use automatic welding machine to connect solar cells in series
All the solar cells are made by top class brand, like TW Solar, Longi Solar
Automatic laying of EVA, backing, automatic cutting of excess backing material 100% automation of the entire production process
Ensure Colour and Power Difference. Ensure high yields,consistent performance and durability, First of 52 steps strict quality control and inspection process.
Visual Inspection
Through the turning machine, completely inspect the solar panel after lamination, and record the defects and feedback to the previous process
100% Optimal Testing
Ensure 3% Positive Power Tolerance Comprehensive QC information management system with barcode ID.Quality traceable system in place to allow quality data flow constantly.
