Main Features:
Adopting frequency converter speed control, the all-round scraping blending is able to produce high quality product produced with different workmanship based on customer requirements.
♦A diversified high speed homogenizer, with intensive mixing of solids & liquid raw materials and fast dissolving of indissolvable materials like AES, AESA and LSA etc., saving energy and production time considerably.
♦Welding fabricated by three layers of stainless steel boards with body and pipelines bright finished, the tank is fully up to GMP requirements.
♦ According to different requirements of workmanship, the tank body can head and cool materials with the way of heating by steam or electricity and with convenient material discharging either by direct discharging or being configured with pump for discharging.
Product Details:
1. Main Tank:
* Capacity: Working Volume: 50-5000L
2. Jacket: It is jacketed for circulation or cold water and steam（can choose Single Layer Tank）
3. Lid Parts: Half open hinged lid
* GMP hygiene standards, made for SUS304(Can do cusotmized), Can open the lid at any time during the making products process, easy to cleaning
4. Water circulation:Mechanial seal cooling system. Protect the Homogenizer to use longer（can choose Single Layer Tank）
5. Agitator Motor:
* SIEMENS motor and reducer (can change to ABB motor)
6. Agitator:
* Mixing part: Frame oar scraping blender with one fixed oar.
* Stirrer paddle: Stir up and down, mixing more evenly.
* Wall Scraper: PTFE material, Scraping off the materials that stick on pot wall, to make all materials mixing more evenly.
7. Bottom Homgenizer(can choose upper homogenizer):
* SIEMENS motor
* Speed: 0-3600rpm
* Homogenizer part: Rotor and stator adopts wire-cutting finish machining high shearing homogenizer, smooth emulsion to 2μm.
8. Discharge part:Bottom discharge, dished bottom design and bottom flat valve to make discharge completely.
9. Electric control system & Platform
* Shell material: SUS304, thickness: 2mm
* Standard Configuration: Instrument, button, appliance components
* All SUS and equipped with anti-skid plate
Applicable Products:
1) Cosmetics
Skin cream, shaving cream, shampoo, cold cream, cold sun cream, cleanser, moisture cream, detergents, serums, moisturizers, hand cream and so on.
2) Daily chemical
Laundry detergent, hand sanitizer, toilet clean, automotive glass washer fluid and so on.
3) Pharmacy Industry
Latex, emulsions, salves (ointments), oral syrup, oral liquid and so on.
4) Food Industry
Sauce, Juice nutrient solution, infant food, chocolate, saccharides and so on.
5) Chemical Industry
Latex, sauce, saponification products, paints, coatings, resins, adhesives, lubricants and so on.
Our Servers:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, Maintenance service.
