Heat Reflective Sleeve with Hook and Loop Closure

VALFS aluminum foil coated fiberglass heat reflective sleeve with velcro has hook and loop closure added to result in a sleeve that can be installed and removed at will.



Description

VALFS Aluminum Fiberglass Sleeve with Velcro is a aluminum coated fiberglass heat reflective sleeve with velcro hook and loop closure and reflects more then 95% radiant heat. This sleeve is easily wrapped over the wires, cables and hoses, then closed with the velcro.


Features

This high temperature, heat resistant and radiant heat reflective sleeve can be used to protect industrial wires, cables, hoses (hydraulics), piping and tubing from radiant heat sources such as glowing steel slab, liquid metal pour stream, infrared heaters and other similar sources.


Application

It is used to protect the industry & automotive wires, cables, hydraulic hoses, piping and tubing from radiant heat sources.


Specifications

DATASHEET
Part Number Normal Inside diameter Meter for spool
Inches mm Dash # Meter
VALFS-16 5/8 16 -10 50
VALFS-19 3/4 19 -12 50
VALFS-22 7/8 22 -14 50
VALFS-25 1 25 -16 50
VALFS-29 1 1/8 29 -18 50
VALFS-32 1 1/4 32 -20 50
VALFS-35 1 3/8 35 -22 50
VALFS-38 1 1/2 38 -24 50
VALFS-41 1 5/8 41 -26 50
VALFS-44 1 3/4 44 -28 50
VALFS-48 1 7/8 48 -30 50
VALFS-51 2 51 -32 50
VALFS-57 2 1/4 57 36 50
VALFS-60 2 2/5 60 -38 50
VALFS-64 2 1/2 64 -40 50
VALFS-67 2 5/8 67 -42 50
VALFS-70 2 3/4 70 -44 50
VALFS-73 2 7/8 73 -46 50
VALFS-76 3 76 -48 50
VALFS-83 3 1/4 83 -52 50
VALFS-89 3 1/2 89 -56 50
VALFS-95 3 3/4 95 -60 50
VALFS-102 4 102 -64 50


Technical Datasheet
Material Aluminum, fiberglass
Working temperature -40 - +260
Flammability VW-1
Melting point +537
Standard Color Silver
Standard Thickness 0.8 mm
MOQ 100 meter each size
Cutting tool Scissors

Notes:
Special thickness upon request
Special length or packing upon request.
Special size upon request.
