Features:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
1) Manufacturer, 32 years professional experience.
2) Two years guarantee term provided freely.
3) Export more than 1000 units to Africa, Southeastern Asia, and South America.
4) Products can be custom-made according to your design.
Specification:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
|
Main Frame
|
Q235B manganese plates, automatic submerged arc welded
|
|
Floor
|
Steel Sheet 3mm thickness or diamond plate(Also can choose
other thickness, such as 2mm, 2.3mm, 4mm, 5mm, 6mm)
|
|
Axle
|
13T FUWA (BPW optional)
|
|
Suspension
|
Independent stamping steel rigid suspension ( air suspension)
|
|
King Pin
|
2" or 3.5" Chinese traction pin ( JOST optional)
|
|
Landing Gear
|
Chinese brand loading 28000kg (JOST optional)
|
|
Wheel Rim
|
12 units of 8.0-20 9.0-20
|
|
Tyre
|
12 units of 11.00R20/12R22.5 16PR steel tyre
|
|
Spare Wheel Carrier
|
One set of spare wheel carrier including a riser.
|
|
Braking System
|
KEMI or other Brand of China; ABS (optional )
|
|
Brake Air Chamber
|
Four double and two single chamber
|
|
Electrical System
|
1. Voltage: 24v 2. Receptacle: 7 ways(7 wire harness)
|
|
Painting
|
Sand blasting processing clean rust
1 coat of anti corrosive primer
2 coats of finish urethane paint
Color as customer need
|
|
Accessory
|
One tooling box with a set of standard trailer tool
|
|
Usage
|
Is applicable for the transplantation of the mechanical equipment,
large objects, highway construction equipment, large tanks, power
plant equipment or machine, and all sorts of steel products.
|
|
Other Descriptions
|
The cargo platform is lower than others, is applicable for unsound
road condition, ensuring the stability of the transportation.
|
|
Other Specifications
|
It' s concave structured with tyre appeared style, the height of the
cargo' s carrying platform from ground is 900mm, (ladders belong
to optional components), with the overall height of 1710 mm
|
|
remark
|
we can designed model according to client' s requirement
|
Production detail:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Producing process:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Loading and Packing:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Our advantage and ability:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
What others we can supply:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
FAQ:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
1. Who are we?
Answer: We are a group company; we have three semi-trailer factories in china, one trading company in china and one company inHong Kong. We are focus on semi-trailer, trucks and parts.
2. Why choose us
Answer: 1) We have more than 30years experience in the trailer manufacturing. Our brand”SUNSKY” and”JUPITER” had got high reputation in china and overseas countries.
2) We have more than 20 engineers to design the kinds of trailers according to the requirement from you.
3) We had exported thousands of trailers to Africa, Middle East, Asia,Australia,South America and so on since 2006.
4) We are one of the biggest dealers of SINOTRUK HOWO truck in china, we can supply kinds of HOWO brand truck with competitive price.
