Product Description
Bluesun HEX5 series monocrystalline solar panels use half cell PERC cells,it has a passivated rear side and a laser grooving process,which significantly improves the cell efficiency,power range from 540-560w.Passed IEC 61215, IEC 61730,UL 61730,INMETRO test for harsh environment.
*High module conversion efficiency *Withstanding harsh environment
*Excellent Anti-PID performance *Excellent weak light performance
|
Module Type
|
BSM540M10-72HPH
|
BSM545M10-72HPH
|
BSM550M10-72HPH
|
BSM555M10-72HPH
|
BSM560M10-72HPH
|
|
|
STC
|
NMOT
|
STC
|
NMOT
|
STC
|
NMOT
|
STC
|
NMOT
|
STC
|
NMOT
|
|
Maximum Power(Pmax/W)
|
540
|
402
|
545
|
406
|
550
|
410
|
555
|
413
|
560
|
416
|
|
Operating Voltage(Vmpp/V)
|
41.96
|
38.29
|
42.06
|
38.35
|
42.16
|
38.43
|
42.24
|
38.52
|
42.33
|
38.59
|
|
Operating Current(Impp/A)
|
12.87
|
10.50
|
12.96
|
10.58
|
13.05
|
10.66
|
13.14
|
10.73
|
13.23
|
10.80
|
|
Open-Circuit Voltage(Voc/V)
|
49.60
|
46.12
|
49.70
|
46.21
|
49.80
|
46.31
|
49.90
|
46.40
|
50.00
|
46.49
|
|
Short-Circuit Current(Isc/A)
|
13.74
|
11.10
|
13.84
|
11.18
|
13.94
|
11.27
|
14.04
|
11.34
|
14.14
|
11.42
|
|
Module Efficiency(%)
|
20.90
|
21.10
|
21.30
|
21.49
|
21.68
|
STC: Irradiance 1000W/㎡,Cell Temperature 25°C,Air Mass AM1.5 NMOT: Irradiance at 800W/㎡,Ambient Temperatue 20°C,Air Mass AM1.5,Wind Speed 1 m/s
