HFD 75 Glass Bi-Folding Door Used on Villa and Commercial Building
HOMI aluminum bifold patio doors Systems offer premium aluminum construction, visual elegance and the high-end form and function you want for your home. Whether your project is remodeling, or a new construction, HOMI Bi-Fold Folding Glass doors will add beauty and value to your home.
- Folding door is widely used in villa and commercial building. It employs a big facade folding way to open; when a user opens the door the door is folded aside and minimizes the obstacle area, thereby expanding the space, like a screen.
- It can meet different customers' need with different open ways, such as opening with a sash or opening with double sash.
- The fly screen could be installed outside, meeting different needs of customers.
- With upper rail and thick profiles, the load-bearing of single sash reaches 150KG and the height can reaches 6meter. Large elevation opening is also acceptable thereby to meet customer requirements for permeability.
| Parameters |
Sash Width/Height
(mm) |
Visible Width
(mm) |
Depth
(mm) |
Glass Thickness(mm) |
|
Width 720-3300mm
Height 1920-3000mm
Weight 100kg
|
Fame Width 56mm
Sash Width 69mm
|
Frame Depth75mm
Sash Depth 65mm
|
SGU:
6-10mm
DGU:
19-28mm |
| Performance |
|
Heat Insulation
W(m2.k)
|
Sound Insulation
(DB)
|
Water Tightness
(Pa)
|
Air Tightness |
Wind Load
(KPA)
|
|
2.5-3.0
level 5/6
|
35DB
level 4
|
350PA
level 4
|
level 6 |
2.5KPA
level 3
|
Customized - HOMI is a aluminium manufacturer with over 30 successful years of valuable experience in this industry. Our teams bring the most professional and competitive suggestions for your engineer and design needs, providing solutions on various sizes and complex projects.
Technical Support -The independent local and abroad technology teams provide aluminium curtain walls technical support (such as wind load calculation, systems and façade optimization), installation guide.
System design -Based on the clients' and market's requirement, develop new aluminium windows and doors systems, match excellent accessories, which can better meet the client target market requirement.
Q: Are you trading company or manufacturer?
A: We are aluminium manufacturer located in QINGYUAN with more than 30 years experience. And you are warmly welcomed to visit us.
Q: How long is your delivery time?
A: Generally it is 15-20 workdays after receiving payment.
Q: Do you provide samples for free? What's the MOQ?
A: The new die samples are free for approval and inspection. The MOQ is 8-10tons
Q: What is the payment terms?
A: 30% upon order confirmation and the balance should be paid before delivery by T/T./after receiving B/L copy. /L/C at sight
