HI 1746-WS WEIGH SCALE MODULE SERIES C

Contact: Miya

Job Title: Sales Manager

Skype: live:miyazheng520

Email: sales@amikon.cn

Tel: 86-18020776792(Whats App )

QQ :2851195450

Brand Name                 AB

Product reference     HI 1746-WS

This manual provides the user and service personnel with a description of the specifications, installation, setup, configuration, operation, communication, maintenance, and troubleshooting procedures for the Hardy Process Solutions HI 1746-WS Weigh Scale Module, designed for use in Allen-Bradley’s SLC 5/ 02, 5/03, 5/04, 5/05 programmable controllers. The HI 1746-WS is equipped with WAVERSAVER®, C2® Calibration, The Button, and INTEGRATED TECHNI- CIAN (IT) diagnostics. The module is configurable via Windows® 95/98/NT HI WS 100 Configuration Soft- ware or RS Logix 500© Industrial Programming Soft- ware. To get the maximum service life from this product, users should operate this module in accor- dance with recommended practices either implied or expressed in this manual. Before using the Weigh Scale Module, all users and maintenance personnel should read and understand all cautions, warnings, and safety procedures, referenced or explicitly stated in this manual, to ensure the safe operation of the module. Hardy Process Solutions appreciates your business. Should you not understand any information in this manual or experience any problems with the product, please contact our Customer Support Depart- ment at: Phone: (858) 278-2900 FAX: (858) 278-6700 e-mail: hardysupport@hardysolutions.com Web Address: http://www.hardysolutions.com NOTE: WAVERSAVER®, C2®, INTEGRATED TECHNICIAN® are registered trademarks of Hardy Process Solutions Inc. Windows® is a registered trademark of the Microsoft Corporation. RS Logix 500© is a Copyright of Rock- well Software Inc. NOTE: Hardy bases all procedures with the assumption that the user has an adequate understanding of all Allen- Bradley SLC 500 products. In addition the user HI 1746-WS WEIGH SCALE MODULE 1-2 should understand process control and be able to interpret ladder logic instructions necessary to gener- ate the electronic signals that control your applica- tion(s). About Hardy Manuals Every Hardy Installation and Operation manual is organized into easily referenced chapters, that are almost always the same:

• Chapter 1 - Provides an introduction to the instrument and an Overview of the equipment and its capabilities. •

Chapter 2 - Provides a complete list of Specifi- cations.

• Chapter 3 - Contains information needed to install the HI 1746-WS (both standard and optional equipment) and the HI 215IT series Junction Box.

 • Chapter 4 - Provides complete hardware Con- figuration instructions for setting dip switches and jumpers.

• Chapter 5 - Pertains to the firmware/software Setup and preparation procedures to calibrate and operate the instrument.

• Chapter 6 - Provides all Calibration instruc- tions.

• Chapter 7 - Pertains to the Operating Proce- dures of the HI 1746-WS.

• Chapter 8 - Pertains to the Troubleshooting procedures for repair of the instrument. Hardy Process Solutions hopes that this manual meets your needs for information and operation. All correc- tions or suggestions for improvements of this manual are welcome and can be sent to the Technical Publica- tions Department or Customer Support Department at Hardy Process Solutions Inc. Description The HI 1746-WS Weigh Scale Module is a self con- tained microprocessor based I/O module with control inputs and outputs, that is designed to be easily plugged into the back plane of an Allen-Bradley SLC 5/02, 5/03, 5/04 or 5/05 programmable controller and/ or Remote Rack. The HI 1746-WS Weigh Scale Mod- ule can be configured to operate as either a local or Chapter 1 - Overview 1-3 remote module. The HI 1746-WS module can be used for a wide variety of process weighing applications such as batching, blending, filling/dispensing, check weighing, force measurement, level by weight and weight rate monitoring. The module can control two (2) relays via two (2) TTL level outputs and transmits data via the back plane to the SLC. The 20 bit analog to digital converter in the weigh module controller updates twenty (20) times per second and is capable of 985,000 counts of display resolution. This gives the instrument the ability to tolerate large “dead” loads, over sizing of load cells/sensors and still have suffi- cient resolution to provide accurate weight measure- ment and control. The HI 1746-WS module is set up by using the SLC 500 AI Series, RS Logix500© Industrial Programming Software for Windows® 95/ 98/NT or the optional Hardy Windows® 95/98/NT HI WS100 Configuration Software. The software config- uration applications must be installed in a PC with either Ethernet, DH+, DH-485, or RS-232-C that can initiate communications with the SLC 5/02, 5/03, 5/ 04 or 5/05. To calibrate the module you can simply push “The Button” to effect a C2 calibration. C2, Hard (Traditional calibration with weights), and Soft calibration can be implemented from the SLC 500 AI Series DOS software, RS Logix500© Industrial Pro- gramming Software for Windows® 95/98/NT or from the optional Hardy WS 100 Configuration Software for Windows. The HI 1746-WS is IT (Integrated Technician) enabled which means the module has a built in IT excitation monitor to detect some load cell problems and with the addition of the optional HI 215IT Junction Box and the HI WS100 software, the operator can use the other IT functions for fault isola- tion troubleshooting of the weighing system.

Every Hardy Installation and Operation manual is organized into easily referenced chapters, that are almost always the same: • Chapter 1 - Provides an introduction to the instrument and an Overview of the equipment and its capabilities. • Chapter 2 - Provides a complete list of Specifi- cations. • Chapter 3 - Contains information needed to install the HI 1746-WS (both standard and optional equipment) and the HI 215IT series Junction Box. • Chapter 4 - Provides complete hardware Con- figuration instructions for setting dip switches and jumpers. • Chapter 5 - Pertains to the firmware/software Setup and preparation procedures to calibrate and operate the instrument. • Chapter 6 - Provides all Calibration instruc- tions. • Chapter 7 - Pertains to the Operating Proce- dures of the HI 1746-WS. • Chapter 8 - Pertains to the Troubleshooting procedures for repair of the instrument. Hardy Process Solutions hopes that this manual meets your needs for information and operation. All correc- tions or suggestions for improvements of this manual are welcome and can be sent to the Technical Publica- tions Department or Customer Support Department at Hardy Process Solutions Inc. Description The HI 1746-WS Weigh Scale Module is a self con- tained microprocessor based I/O module with control inputs and outputs, that is designed to be easily plugged into the back plane of an Allen-Bradley SLC 5/02, 5/03, 5/04 or 5/05 programmable controller and/ or Remote Rack. The HI 1746-WS Weigh Scale Mod- ule can be configured to operate as either a local or Chapter 1 - Overview 1-3 remote module. The HI 1746-WS module can be used for a wide variety of process weighing applications such as batching, blending, filling/dispensing, check weighing, force measurement, level by weight and weight rate monitoring. The module can control two (2) relays via two (2) TTL level outputs and transmits data via the back plane to the SLC. The 20 bit analog to digital converter in the weigh module controller updates twenty (20) times per second and is capable of 985,000 counts of display resolution. This gives the instrument the ability to tolerate large “dead” loads, over sizing of load cells/sensors and still have suffi- cient resolution to provide accurate weight measure- ment and control. The HI 1746-WS module is set up by using the SLC 500 AI Series, RS Logix500© Industrial Programming Software for Windows® 95/ 98/NT or the optional Hardy Windows® 95/98/NT HI WS100 Configuration Software. The software config- uration applications must be installed in a PC with either Ethernet, DH+, DH-485, or RS-232-C that can initiate communications with the SLC 5/02, 5/03, 5/ 04 or 5/05. To calibrate the module you can simply push “The Button” to effect a C2 calibration. C2, Hard (Traditional calibration with weights), and Soft calibration can be implemented from the SLC 500 AI Series DOS software, RS Logix500© Industrial Pro- gramming Software for Windows® 95/98/NT or from the optional Hardy WS 100 Configuration Software for Windows. The HI 1746-WS is IT (Integrated Technician) enabled which means the module has a built in IT excitation monitor to detect some load cell problems and with the addition of the optional HI 215IT Junction Box and the HI WS100 software, the operator can use the other IT functions for fault isola- tion troubleshooting of the weighing system.

RELATED PRODUCT

If you have any question pls do not hesitate to contact us.We can supply all kind of the automation parts,if you want to purchase parts pls send the parts model to my mail, I will prompt reply you as I receive the mail.Hope anyone inquire from us.    Waiting for your inquiry.
