Product Name
High CCA LiFePO4 Pack 12V Lithium Racing Battery Plug-and-Play
What distinguishes us from other battery supplier are:
1.High quality BMS (Battery Management System) :We use Mult-functional 100A continuous BMS with built-in IC compatible with military standards for over-current, over-discharge, over-charge, short-circuit, adverse-polarity connection, balancing functions.
The has 3-folds of over current protection:(1) continuous discharge current of 100A ;(2) 125A protection for 30s;(3) 400A for 3-5 s protection.
And the MOSFET and IC, the most important parts of BMS, are all quality brand.
2.Automatic Welding , quality assembly materials and exquisite workmanship: the battery packs are spot welded by automatic welder (please check attached pictures) for high accuracy and minimized energy consumption; and all the welding materials including nickle tabs and wires can resist high current; our worked are trained for skills and expertise.
3.Strict QC standards: we have strict QC procedure and standards to keep the failure rates under 0.2%.
Technical Specification
|
Model
|
OSN-CSB-
1220
|
OSN-CSB-
1240
|
OSN-CSB-
1260
|
OSN-CSB-
1280
|
OSN-CSB-
12100
|
OSN-CSB-
12200
|
|
Nominal voltage
|
12.8V
|
|
Nominal capacity
|
20Ah
|
40Ah
|
60Ah
|
80Ah
|
100Ah
|
200Ah
|
|
CCA (Cold Cranking Amp)
|
400A
|
600A
|
800A
|
1000A
|
1200A
|
1400A
|
|
Lenght (mm)
|
260mm
|
260mm
|
260mm
|
260mm
|
260mm
|
260mm
|
|
Width (mm)
|
175mm
|
175mm
|
175mm
|
175mm
|
175mm
|
175mm
|
|
Height (mm)
|
210mm
|
210mm
|
210mm
|
210mm
|
210mm
|
210mm
|
|
Weight
|
3.5Kg
|
6Kg
|
8Kg
|
10Kg
|
12Kg
|
14Kg
|
|
Lead-Acid equivalent(pb eq)
|
60Ah
|
120Ah
|
180Ah
|
240Ah
|
300Ah
|
600Ah
|
|
Charge mode
|
Constant Charge / Constant Voltage
|
|
Recommended Charge Method
|
CC/CV 14.4V
|
|
BMS Cut-Off voltage
|
14.6V ± 0.1V
|
|
BMS Cut-Off voltage
|
8.0V (cut-off is triggered after start attempt)
|
Application
OSN LiFePO4 automotive batteries are designed to replace 12V lead-acid starter batteries for competition vehicles or high power application
We embed powerful Lithium Iron Phosphate cells designed to provide extreme discharge current, applicable for Quads, Motorbike, heavy-duty vehicles.
Using Ultra safe Lithium iron phosphate, also known as LFP or LiFePO4, this element is considered to be the safest material among lithium in batteries, not hazardous for human, no thermal run-away and never explode.
-
High safety with advanced Built-in Battery Management System;
-
Enclosed in a sealed plastic case, resistant to moisture and dust;
-
High lifespan up to thousands of cycles.
Please contact us at service@osnpower.com or +86-18575517952 .
