High Current Battery Short Circuit Testing Machine For Lithium Battery Safety Performance Testing
SPECIFICATIONS
|
Type
|
TOB-BE-1500A
|
TOB-BE-2000A
|
TOB-BE-5000A
|
|
Short circuit current
|
1000A、1500A
|
1000A、2000A
|
2000A、5000A
|
|
Temperature explosion - proof box
|
0~100°C can be choose
|
|
DC Response Time
|
≤5us
|
|
Device resistance
|
≤5mOhm
|
|
Remote distance
|
7m No solid obstacle
|
|
Short circuit time
|
1~9999S or 1M~99H59M can be set
|
|
Dimension
|
W650*D730*H970mm
|
|
Explosion-proof box size
|
W1000*D1000*H1000mm,thickness:8mm
|
|
Power supply
|
AC220V 50HZ
|
|
Power
|
1.0KW
|
|
Weight
|
About380Kg
|
