High Quality 440HP Beiben V3 6x4 truck head
Model
|
ND42500B34J7
|
Traction type
|
6X4
|
Driving type
|
LHD
|
Driver's cab
|
Long high cabin, double sleeper bunk, A/C
|
Dimensions in (mm)
|
Wheel base(mm): 3450+1450
|
|
Overall size(mm): 7240x2500x3600
|
Engine
|
Maker: Weichai
|
|
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling
|
|
Engine model: WP12.440(440hp)
|
|
Emission Standard: EURO3
|
|
Maximum output: 1920NM /1200-1500 rpm
|
|
Number of cylinder:6
|
|
Displacement: 9.726L
|
Clutch
|
430mm, hydraulically operating with air assistance
|
Transmission
|
Brand: FAST
|
Model: 12JS200T(12 speeds)
|
Steering
|
TAS85
|
Front Axle
|
Benz technology 7.5ton
|
Rear Axle
|
Benz 13ton double reduction driving axle,Ratio:4.2
|
Types
|
12.00R20 Radial tyre
|
No. of tyre
|
10+1(spare)
|
Fifth wheel
|
3.5’(90#)
|
Fuel tank(L)
|
400 Aluminium
|
Electrics
|
Operating voltage: 24V, negative grounded
|
Weight in kg
|
Kerb weight 8800kg
|
|
Total mass 25000kg
|
Performance
|
Maximum driving speed(km/h) 110
|
