Main Parameter
|
Subject
|
Parameter
|
|
Stable Speed
|
150-300m/min (According to your order)
|
|
Pass Percentage
|
≥97%
|
|
Operating Rate
|
≥85%
|
|
Power Supply
|
380V 50Hz
|
|
Electrical Supply
|
380V ±5%, 50Hz Three-phase four-wire + ground wire
|
|
Power Installed
|
About 400KW (Not included hot melt glue machine)
|
|
Supply Pressure
|
0.6-0.8Mpa
|
|
Machine Sizes (L× W× H )
|
22.0m× 5.5m× 3.5m(L× W× H )(Only for reference)
|
|
Main Engine Sizes (L× W× H )
|
32m× 9.0x 5.0m (L× W× H ) ( Only for reference)
|
|
Machine Color
|
Customerized
|
|
Product structure
|
Leg cuff N.W., Topsheet N.W., Fluff core (with SAP), Side tape, Elastic Waistband, Frontal tape, Backsheet.
|
|
Product size
|
M: 680*450mm, L: 800*650mm, XL: 950*760mm
|
|
Contral system
|
PLC control system, operating on the touch screen, man-machine interface.
|
|
Tension system
|
Leg cuff N.W., Topsheet N.W., elastic waistband, upper & down tissue, backsheet are A&B shaft active unwinding by inverter motor.
|
|
Drive system
|
Servo Drive (Easy to change size), timing belt and flat belt are imported products, and all the key parts are using imported bearings.
|
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch. High audio fan uses sound insulation or silencer.
|
|
Packing way
|
Equipped with the stacker at the request of client.
|
|
Materials corrective system
|
Germany BST automatic web guide system (optional)
|
