Specification of Boron Nitride coating:
|
Part No.
|
Particle
|
Purity
(%)
|
SSA
(m2/g)
|
Bulk density
(g/cm3)
|
Density
(g/cm3)
|
Crystal
|
Color
|
BN0507-500N
|
0.5um
|
99
|
16
|
0.45
|
2.25
|
Hexagonal
|
white
|
BN0507-1U
|
1-3um
|
99
|
9
|
1.6
|
2.25
|
Hexagonal
|
white
|
Note: We can supply different size products of Boron Nitride coating according to client's requirements.
Environmental characteristics: Boron nitride is an environmentally friendly material, non-toxic, non-polluting
Chemical characteristics: Strong non-stick properties in high temperature environment, high temperature stability
Physical properties: Electrical insulator, low dielectric constant, good thermal conductivity and high lubricity
Product Features: Special formula, water-based matrix, easy to use, long-acting formula
Application of Boron Nitride coating:
1. Increase the heat conduction, so that the heat source can be dispersed faster, thereby increasing the service life of the mechanical body and its use efficiency. Liquid thermal conductive coatings are converted into various modules, parts, heat exchangers or exteriors that require improved thermal and thermal efficiency. They are coated with a special chemical formula to coat the heat-dissipating coating on the original surface, increasing the original surface area to more than tens of times. Conditions that increase the effect of heat convection.
2. Suitable for all kinds of release agents that need to be used under high temperature operation (this product can withstand high temperature 2800 ° C). For example, glass industry, metal welding industry, etc., can effectively lubricate and isolate the interface to make various processing processes more For smoothness. The sintering of metal and ceramic powders is usually carried out on a graphite plate. After coating a layer of boron nitride coating on graphite, it can obviously remove the contamination, reaction and adhesion of carbon to the sintered parts during the sintering process.
SEM & XRD of Boron Nitride coating:
Storage conditions:
Boron Nitride coating should be sealed and stored in a dry and cool environment. It should not be exposed to the air for a long time, to prevent agglomeration due to moisture, affecting the dispersion performance and use effect, and should avoid heavy pressure, do not contact with oxidant, and transport according to ordinary goods.
