F 3331: 8 fold output module, testable safety related
resistive load or inductive load up to 500 mA (12 W),
lamp connection up to 4 W,
with integrated safety shutdown,
with safe isolation, with line monitoring,
no output signal with break of the L- supply
requirement class AK 1 ... 6
Contact: Miya
Skype: live:miyazheng520
Email: sales@amikon.cn
Tel: 86-18020776792(Whats App )
QQ :2851195450
Description
The module is automatically tested during operation. The main test routi- nes are:
– Reading back of the output signals. The operating point of the 0 signal read back is ≤ 6.5 V. Up to this value the level of the 0 signal may arise in case of a fault and this will not be detected
– Switching capability of the test signal and cross-talking (walking-bit- test)
– line monitoring.
|
Outputs
|
500 mA, k short circuit proof
|
|
Internal voltage drop
|
max. 2 V at 500 mA load
|
|
Admissible line resistance (in + out)
|
max. 11 Ohm
|
|
Undervoltage tripping
|
at ≤ 16 V
|
|
Outp. leakage current
|
max. 350 µA
|
|
Output voltage if output is reset
|
max. 1.5 V
|
|
Current input WD
|
max. 30 mA
|
|
Duration of the test signal
|
max. 200 µs
|
|
Space requirement
|
4 TE
|
|
Operating data
|
5 V DC: 130 mA
24 V DC: 180 mA in add. load
|
