F 6217: 8 fold analog input module, safety related
Contact: Miya
Skype: live:miyazheng520
Email: sales@amikon.cn
Tel: 86-18020776792(Whats App )
QQ :2851195450
Description
for current inputs 0/4...20 mA, voltage inputs 0...5/10 V, with safety isolation resolution 12 bits tested according to AK6/SIL3
The module contains a redundant, safety related processor system. Be- cause of this, all the tests are executed directly on the module. The main test routines are:
- Linearity of the AD converters
- Cross talking between the 8 input channels
- Function of the input filters
- Function of the IO bus communication
- Selftests of the microcontrollers - Tests of the memories
|
Input voltage
|
0...5.5 V
|
|
max. input voltage
|
7.5 V
|
|
Input current
|
0...22 mA (via shunt)
|
|
max. input current
|
30 mA
|
|
R*: Shunt with
|
250 Ohm; 0.05 %; 0.25 W;
|
|
current input
|
T
|
|
Resolution
|
12 bit, 0 mV = 0
5.5 V = 4095
|
|
Measurand up date
|
50 ms
|
|
Safety time
|
< 450 ms
|
|
Input resistance
|
100 kOhm
|
|
Time const. inp. filter
|
appr. 10 ms
|
|
Basic error
|
0.1 % at 25 °C
|
|
Operating error
|
0.3 % at 0...+60 °C
|
|
Electric strength
|
200 V against GND
|
