Wide operating voltage range: The 10310/1/1 ELD can operate with a wide range of voltages, from 16 to 32 Vdc. This makes it suitable for a variety of applications, such as industrial control systems, building automation systems, and renewable energy systems.
|
|
|
|
10310/2/1 Data sheet
|
The ELD module connects earth level with –12 Vdc (referenced to the 0 V connection of the 24, 48, 60 and/or 110 Vdc supply).
|
|
A 1.5 kOhm resistor in the ELD with its own connection to earth (on the Earth2 pin) allows testing of the ELD and the earth connection (switch 2 in 'TEST' position).
|
|
The ELD module can be tested by connecting a 1.5 kOhm resistor between 0 V and earth. This should set the flip-flop.
|
|
