Product Description:
All models of the Low Level Analog Input Multiplexer (LLMux) Field Termination Assemblies (FTAs), the Power Adapter, and its IOP can be used in a CE Compliant application. However, they must be used with the model MU-KFTSxx IOP to FTA cable and the IOP must be installed in a CE Compliant card file. the LLMux FTA, model MU-TAMR03 or
MU-TAMT03/13, communicates with a model MU-PLAM02 LLMux IOP
through the model MU-TLPA02 Power Adapter. This can be a non-CE
Compliant or CE-Compliant application depending upon the model of the
card file that is used.
The LLMux FTAs that connect to the Power Adapter can be either of two
types of FTAs; the model MU-TAMT03/13 Thermocouple (TC) FTA or the
model MU-TAMR03 Resistive Temperature Device (RTD) FTA. The
combination of the FTA mother board and the daughter board determines
the type of FTA.There are two versions of the Thermocouple LLMux FTA. The model
MU-TAMT03 FTA has a single local Cold Junction Reference (CJR)
interface, while the model MU-TAMT13 FTA has a remote CJR interface.
This allows the CJR to be located up to 50 meters (164 feet) from the FTA
with the use of appropriate cabling.
