Higao Tech produce good quality
horizontal airflow vibrating screen machine is more suitable for screening of ultra-light, multi-fiber materials in china.
1. Introduction:
Horizontal airflow vibrating screen machine is a separating equipment fit for sieving and screening materials which contains many fiber, high viscosity, high electrostatic, light specific gravity, easy reuniting/aggregation.
Used widely in pharmaceutical, chemical, foodstuff industry. Beside, it can break the powdery blocks which gather together easily.
2. Working Principle and Features:
The shape of the mesh is cylindrical and placed inside the machine. After the material is fed into the machine and mixed with the high speed airflow through the screw conveying system, and then atomized into the screen cylinder.
The rotating blades generates the centrifugal force and cyclone impellent force simultaneously. So the material is sprayed over the sieve mesh, the material smaller than the mesh hole is discharged, and the material bigger than the mesh hole will advance forwards and discharged from the coarse outlet port along the tube wall to achieve the purpose of efficient screening.
Automatic mesh self-cleaning by airflow, no jam, no noise, good sealing, high efficiency and no flying dust.
