Horizontal Lead Stripper Type BQ-180
Product Description:
Automatic Wire Stripping Machine Can do wire separate, strip, twist, solder/tin & cut at one time because we put all the moulds together in one machine. This machine's stripper moulds can do stripping for single conductor cable wire, double-conductor cable wire, two lane model wire.
Specification Parameters:
Central height
|
1000mm
|
Linear speed
|
(max) 11 meter/min
|
Cutting depth
|
1~8mm (adjustable)
|
Diameter range of metallic sleeve
|
φ25~φ180mm
|
Main motor
|
5Kw, AC motor with frequency change
|
Features:
1. Efficient, precise cable peeling machine made to last with capacity of peeling about 18 AWG - 1" OD wires. It’s common knowledge for anyone who has tried a standard peeling machine that much time and energy can be wasted by adjusting blades up and down repeatedly. However this machine will definitely save your time.
2. This wire stripper owns 11 channels for you to peel your wires. Top spring loaded mechanism allows tension adjustment of the cutters depending on wire or jacket size you are cutting, such design also prolongs blade life.
3. The cable stripper is motor and gear driven.
4. Easy to operate and labors are saved and improving output,enhance productivity,safety,save manpower.
In 2003, Ito-sin(DeYang) Wire & Cable Equipment Co.,Ltd. was awarded the certificate of quality administration system issued by Britain DAS authority and the certificate of quality administration system approved by Britain UKAS authority. In 2005, it was approved by the international wire & cable association as one of the standing members.
Application and Transmission:
1. Lead strip machine is mainly used for stripping lead off lead-clad rubber pipe.
2. Transmission comes from a 15kW motor with frequency change via K series of gear reducer, goes through toothed belt to the gear and makes the upper, lower hauling barrels, the upper and lower cutting blades to perform synchronized cutting of the metal sheath into pieces.
FAQ:
Q1. What information should I let you know if I want to get a quotation?
A: Item Name,Size,Initial Quality you require.
Q2. How to make the payment?
A: T/T
Q3. When will you deliver the machine?
A: Delivery Time for 30-40 days.
