Product Description:
Distance:100 m
Data Rate (max):112 Gb/s
Protocol:OTN OTU4 Compliant 100G Ethernet Compliant
Low End Case Temperature (°C):-5
High End Case Temperature (°C):75
Diagnostics:Digital
Transmitter:4x VCSEL Array
Receiver:PIN
Voltage Supply:3.3
Connector:MPO (MTP12)
Wavelength:850nm Band
Product Feature:
Hot-pluggable CFP4 form factor
Supports 103.1Gb/s and 112Gb/s aggregate bit rate
Power dissipation <4W
RoHS-6 compliant
Single 3.3V power supply
Maximum link length of 100m on OM4 Multimode Fiber (MMF)
4x28Gb/s 850mm VCSEL-based transmitter
4x28G electrical interface
Single MPO12 receptacle
MDIO management interface
Commercial case temperature range: 0°C to 70°C
