Main features:
Engine: Adopt Cummins or Weichai turbocharging
engine, powerful, energy. conservation,environmental
protection, satisfies the requirement of high efficiency operation.
Transmission
& torque converter: Use
hydraulic power shift transmission, big traction in combined operating
condition, the transmission system is more
reliable. Adopt double turbine hydraulic torque converter, single lever control for the speed changing,
easier for operation.
Driven
axle: Reinforced heavy duty type driven axle, hub reduction, high strength
axle case, large load capacity, excellent stability and reliability.
Steering
system: Adopt transverse oil cylinder type steering bridge,
full-hydraulic steering, flexible and light, reliable.
Braking
system: Use four heavy caliper disc brake, thicken brake disc, the rear
air tank. especially have very good
thermostability performance when heavy loaded, braking effect stable. heat
dissipation faster, reliable and safe operation.
Control system: Pilot
valve control device to make
the work efficiency and reduce drivers’ labor intensity.
Hydraulic system: Double pump confluence, small system flow, low power
consumption, reliable performance, excellent operating performance
Cooling
system: Adopt independent transmission oil and hydraulic oil cooling,
increasing system stability.
Frame
structure: Exquisite workmanship &firm box-type
frame, improve the transverse and longitudinal stability of forklifts. The forklifts
get through the 3D finite element analysis, superior structure, reliable
quality, the main welding parts through the nondestructive testing, effective
coordination with the reinforced structure、bridge and frame.
Mast:Box-type
internal-external mast, special all-round roller bearings, increase lifting
performance.
Cab:With air-conditioning
, and rupture
membrane, explosion proof, heat insulation, prevent glare, sound
insulation,damping luxury cab with sunroof, wide view and comfortable seats,
flexible control.
Parameters:
|
Vehicle
configuration
|
|
FD320
|
Performance
|
Rated load
|
|
32000
|
Load center
|
|
1200
|
Mast tilt angle (front/rear)
|
º
|
6/12
|
Overall dimensions
|
Length
|
mm
|
9640
|
Width
|
mm
|
3200
|
Height
|
mm
|
3960
|
Mast lifting height
|
mm
|
4000
|
Fork size (L*W*H)
|
mm
|
2400X300X120
|
Min. turning radius
|
mm
|
6600
|
Max. travel speed (with load)
|
Km/h
|
24
|
Lifting speed (with load)
|
mm/s
|
280
|
Gradeability (with load)
|
%
|
20
|
Weight
|
Kg
|
40000
|
Tyre
|
Front
|
|
16.00-25-32PR
|
Rear
|
|
16.00-25-32PR
|
Wheel tread
|
Front
|
mm
|
2330
|
Rear
|
mm
|
2140
|
Wheelbase
|
mm
|
4800
|
Min. ground clearance
|
mm
|
350
|
Engine
|
Model
|
|
WD10G240
|
Rated power
|
KW
|
178
|
Max. torque
|
N.m
|
786
|
Note: the above data are
subject to change without prior notice.
