SPECIFICATIONS FOR TRACTOR TRUCK
|
Vehicle Specifications
|
Model
|
ND41808A35J7
|
Traction 4X2,6X4,8X4
|
4X2
|
Power
|
290HP
|
Weight Parameter
|
Complete Vehicle Kerb Mass(kg)
|
7020
|
Maximum authorized total mass (kg)
|
34850
|
Dimension Parameter
|
External Dimensions(mm)
|
Length (mm)
|
5995
|
Width(mm)
|
2495
|
Height(mm)
|
3340,3790
|
wheelbase(mm)
|
3500
|
Performance Parameter
|
Maximum Speed(km/h)
|
90
|
Maximum Gradeability(%)
|
35
|
Turning diameter(m)
|
16
|
Recommended Configuration
|
Engine
|
Engine Type
|
WP10.290E32
|
Rated power(kW)/Rev(r/min)
|
213/2200
|
Horse power/(hp)
|
290
|
Torque(N*m)/Rev(r/min)
|
1160/1200-1600
|
Transmission
|
9JS119B
|
gearbox
|
9forward gears
2backward gears
|
Clutch(mm)
|
430
|
Axle
|
Front Axle
|
Benz-7.5t
|
Rear Axle
|
Benz-13t
|
Axle load-bearing
|
Front axle
|
7.5t
|
Front axle
|
13t
|
Fuel Tank(L)
|
400
|
Track(mm)
|
2045/1800,1838
|
Front overhang/rear overhang(mm)
|
16/40
|
Type
|
12.00R20
|
Cabin
|
Sleeper
|
none sleeper
|
OTHER
|
ABS
|
optional
|
COLOR
|
optional
|
Horse power
|
290,310, 340 ,380,
420 is optional)
|
Type
|
nylon(radial and
tubeless is optional)
|
