1. All the trucks will be made antirust before shipment
2. Different shipping method for different port, Ro-Ro Vessel, Bulk Vessel, Flat-Rack, Container, etc
3. Shipment tracking
|
Traction type
|
6x4
|
Driving type
|
LHD
|
Cabin
|
MAN cab, high roof, double sleepers (A/C is optional)
|
Engine
|
Brand
|
Weichai Steyr EURO II
|
Model
|
WD12.420
|
Type
|
Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & intercooling
|
Displacement
|
11.596 liters
|
Max. output
|
420hp@2200rpm
|
Max torque
|
1750NM@1300-1600rpm
|
Bore/Stroke(mm)
|
126/155
|
Mean Position Speed
|
9.53m /s
|
Compression ratio
|
15.5:1
|
Specific fuel consumption
|
198g /Kwh
|
Gearbox
|
Brand
|
FAST (FULLER technology)
|
Model
|
12JS180T manual operation
|
Rated input power
|
331KW
|
Rated input torque
|
1800N.m
|
Max. Input rotation Speed
|
2600rpm
|
Ratio of 12JS180T
|
Lower speed ratio
|
Higher speed ratio
|
Reverse
|
1
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
11
|
12
|
R1
|
R2
|
15.53
|
12.08
|
9.39
|
7.33
|
5.73
|
4.46
|
3.48
|
2.71
|
2.10
|
1.64
|
1.28
|
1.00
|
14.86
|
3.33
|
Axles
|
Front axle
|
MAN tech 7.5 tons drum brake axle
|
Drive axle
|
Steyr 13 tons strengthened axle (punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock)
|
Other technical data
|
Clutch
|
Φ430 diaphragm single disc type
|
Steering
|
ZF technology
|
Frame
|
300mmx80mmx 8mm (inner: 275mm*70mm*5 mm )
|
Tyre
|
12.00-20 (rim: 8.5-20) bias tire
|
Spring suspension
|
10/12
|
Fuel consumption
|
38L/ 100km
|
Fuel tank capacity
|
380
|
Max. speed (km/h)
|
92
|
Max. Gradeability(°)
|
28
|
Kerb. mass
|
9050 kg
|
Total mass
|
25000kg
|
Wheel base (mm)
|
2925+1350
|
Front/rear overhang
|
1525/845
|
Approach/departure angle
|
18/66°
|
Dimension(mm)
|
6645x2495x3750
|
5th wheel
|
3.5" (90mm)
|
