Hot Sealing Cold Cutting Bag Making Machine

Simple operation,

Reasonable design,

Accurate bag making,

Stable running

Machine Characteristics

The whole machine adopts full computer touch control system, Length setting controlling with Delta(TW) AC servo motor.
Arbitrary length setting, color photocell automatic tracking, accurate, stable, automatic stop when missing printing mark. With a puncher holder on machine, Hole puncher is optional.
The machine is widely used in various industrial flat packaging pockets.

Technical Parameters

Model	Unit	22 inch	26 inch	30 inch	40 inch
Max sealing cutting width	mm	500	600	700	900
Max sealing cutting length	mm	600	700	800	1100
Max sealing cutting thickness	mm	0.01-0.2	0.01-0.2	0.01-0.2	0.01-0.2
Length error	mm	0.3	0.3	0.3	0.3
Output per minute	pcs/min	50-150	50-150	50-130	50-110
Starting ac motor	kw	1.5	1.5	1.5	2.2
Delta servo motor	kw	1	1.5	1.5	2
Rear feeding AC motor with frequency conversion	w	550	550	550	550
Electric heat	kw	1.5	1.8	1.8	2.0
Stand-by power of whole machine	kw	4.3	4.6	4.9	7.2
Weight	kg	400	450	550	650
Machine dimensions	cm	195110140	195120140	195130140	195160140

Details Show
