HWIC-1T 1-Port Serial WAN Interface Card

Serial and asynchronous high-speed WAN interface cards (HWICs) provide highly flexible connections for Cisco1800, 1900, 2800, 2900, 3800, and 3900 Series Integrated Services Routers. These HWICs help customers enable applications such as WAN access, legacy protocol transport, console server, and dial access server. You can mix and match HWICs to tailor cost-effective solutions for common networking problems such as remote network management, external dial-modem access, low-density WAN aggregation, legacy protocol transport, and high-port-density support.



HWIC-1T Overview


Serial and asynchronous high-speed WAN interface cards (HWICs) provide highly flexible connections for Cisco1800, 1900, 2800, 2900, 3800, and 3900 Series Integrated Services Routers. These HWICs help customers enable applications such as WAN access, legacy protocol transport, console server, and dial access server. You can mix and match HWICs to tailor cost-effective solutions for common networking problems such as remote network management, external dial-modem access, low-density WAN aggregation, legacy protocol transport, and high-port-density support.


HWIC-1T Specification


Brand Cisco
Part number  HWIC-1T
Product Description 1-Port Serial WAN Interface Card
Synchronous Support
Yes
Synchronous Maximum Speed (Per Port) 8 Mbps
Asynchronous Support Yes
Asynchronous Maximum Speed (Per Port) 115.2 kbps
Bisync Support Yes
Serial Protocols EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21
Network Clock Synchronization Yes
NEBS Type 2/4
TelecommPTT TBR1 and 2
JATE Digital
NEBS
Safety Approvals UL 60950 (United States)
CAN/CSA 22.2, CSA60950 (Canada)
GB 4943 (China)
AS/NZS 60950 (Australia/New Zealand)
EN60950 (Europe)
IEC 60950 (International)
Immunity EN300386
CISPR24
EN55024
EN50082-1
61000-4-2/3/4/5/6/8/11
Emissions FCC Part 15 Class A
ICES-003 Class A
EN55022 Class A
CISPR22 Class A
AS/NZSCISPR22 Class A
VCCI Class A
EN 300386
EN61000-3-2/3
CNS1343
Physical Specifications Singlewide HWIC, no slot restrictions
Dimensions 2.1 x 7.9 x 14.2 cm
Warranty One year
Lead time 2-3 business days
Shipment DHL, Fedex, Aramex, EMS or per request
